DEEPCOOL CAPTAIN 240 PRO V2 ADD RGB

DEEPCOOL CAPTAIN 240PRO V2 ADD RGB.

ANTI-LEAK TECH INSIDE

CAPTAIN 240PRO V2 is equipped with Deepcool’s exclusive Anti-leak Technology. The technology helps the system achieve an automated pressure balance, which will significantly improve operation safety of AIO liquid cooling systems. With this technology, Deepcool is setting a new standard for liquid cooling systems.

STAINLESS STEEL PIPE

CAPTAIN 240PRO V2 upgraded its U-shape pipe from glass to stainless steel, gaining extra sturdiness and machinery-like aesthetics.

ADD-RGB LIGHTING SYSTEM

5V addressable LEDs are installed on both water block and fans. The 16.7M true color flowing RGB system can be easily controlled by the included wired controller or motherboard SYNC software.

EASY TO INSTALL
Unique pre-installed spring screws make the installation on motherboard super convenient.
Accessories like PWM hub and RGB extension cable also allows easy RGB and PWM control.

MOTHERBOARD AND CABLE CONTROL

The 16.7M true color flowing RGB system can be easily controlled by the included wired controller or motherboard (with 5V 3 Pin A-RGB header) SYNC software.

Features:

- Anti-leak Tech Inside, outstanding safety.
- Stainless steel U-shape pipe, sturdy and fashionable.
- Easy-to-install mounting mechanism.
- Abundant accessory pack, convenient for PWM and RGB control.
- Compatible up to TR4 chipsets.
- Dual chamber design, higher heat dissipation efficiency.
- 5V RGB on waterblock and fans, support wire controller and mainstream motherboard control.

Technical Specifications:
Radiator Dimensions: 282Χ120Χ27 mm
Radiator Material: Aluminum
Net Weight: 1617 g
Tube length: 380 mm
Pump Dimensions: 93.7Χ93Χ85 mm
Pump Speed: 2200 RPM±10%
Pump Noise: 17.8 dB(A)
Pump Connector: 3-pin
Pump Rated Voltage: 12 VDC
Pump Rated Current: 0.13 A
Pump Power Consumption: 1.56 W
Fan Dimensions: 120Χ120Χ25 mm
Fan Speed: 500~1800 RPM±10%
Fan Airflow: 69.34 CFM
Fan Air Pressure: 2.42 mmAq
Fan Noise: =30 dB(A)
Fan Connector: 4-pin PWM
Bearing Type: Hydro Bearing
Fan Rated Voltage: 12 VDC
Fan Rated Current: 0.17 A
Fan Power Consumption: 2.04 W
LED Type: Addressable RGB LED
LED Connector: 3-pin(+5V-D-G)
LED Rated Voltage: 5 VDC
LED Power Consumption: 0.9 W(PUMP)/4.8 W(FANΧ2)

Intel

LGA2066/2011-v3/2011/1151/1150/1155/1366

AMD

TR4/AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
