740710 Dual SAT-Terrestrial Combiner LTE
Click to enlarge
Share:
- Item Code: EDSN071339
- Help Code: 12-20-0006
-
Availability:
In Stock
Important: For pick-up from our store service please contact us BEFORE you visit our store in order to avoid any inconvenience.
Item Description
Combiner for MATV and 2XIF signals, with 4G-LTE cut off. DC pass in the IF line.Technical features:
- Mixed bands: TV-FI x2
- MHz: 47 ... 790 και 950 ... 2400
- Inputs with D/C bypass: 2 (SAT), V/A: 50 / 0.5
- MATV through losses dB: 5.5
- IF through losses dB: <1
- MATV-IF rejection db: >10
- Dimensions mm: 98 x 75 x 27
